Planetary Gearboxes

Key features • ABB、SIEMENS and other high-end motors can be installed together with our gearboxes to be sold • WORM WHEEL ADOPTS HIGH QUALITY TIN Bronze， LONG SERVICE LIFE AND MORE DURABILITY. • Factory outlet，provide video factory inspection • The bearing capacity of the single-stage worm gear reducer does not meet the requirements, so a double-stage worm gear reducer combination can be used. • Double-stage combination worm gearbox has a wide range of applications, durability, large transmission ratio, strong self-locking ability, and simple structure. • Speed ratio range:From 300:1to 8000:1 • Input shaft/hole: Customizable • Output shaft/hole: Customizable • Colors: Blue or gray or green or according to customer required • Die-cast aluminum alloy housing • Worm wheel adopts high quality Tin Bronze • Certification:RoHS/CE/IAF/CNAS /ISO9001/ISO45001/ISO14001 • Bipolar reducers: available • Flange: round or square（Customizable） • Delivery time: 50 days(for ready goods,we can deliver them within 2days) • Approximate gross weight: 11 KG Key benefits • Maintenance-free,fully sealed(no need fill oil for whole life) • Good heat dissipation,low temperature rise • Low noise, smooth operation • Energy saving and high efficiency • Can be installed in any position and in all directions • Built-in fully synthetic lubricant, no breather plug Tip: •The whole worm gearbox is warranted for one year •The starting date of the warranty period is subject to the date of the product invoice, please present the invoice when repairing. •Beyond the warranty period or does not belong to the free warranty products, the company's maintenance center is still dedicated to serve you. Contact detail: • If you need special customization or have requirements for delivery time, please contact sales manager: daiyi@chinachenyue.com WhatsApp: +86 173 5260 0137 M: +86 173 5260 0137 Service: +86 400 019 2928

Key features • ABB、SIEMENS and other high-end motors can be installed together with our gearboxes to be sold • Factory outlet，provide video factory inspection • Speed ratio range: from 5:1to100:1 • Input hole: ∅22 • Output hole:from 22mm to 50mm • Rated Input Speed: 1450rpm • Output Speed: 290rpm • Rated Input motor : 0.37kW～3kW • Output Torque Range : 172N·m～233N·m • Colors: Blue or gray or green or according to customer required • Die-cast aluminum alloy housing • Certification:RoHS/CE/IAF/CNAS/ISO9001/ISO45001/ISO14001 • Flange: round or square • Delivery time: 50 days(for ready goods,we can deliver them within 2days) • Approximate gross weight: 10Kg/pc Key benefits • Maintenance-free,fully sealed(no need fill oil for whole life) • Good heat dissipation,low temperature rise • Low noise, smooth operation • Energy saving and high efficiency • Can be installed in any position and in all directions • Built-in fully synthetic lubricant, no breather plug Tip: •The whole worm gearbox is warranted for one year •The starting date of the warranty period is subject to the date of the product invoice, please present the invoice when repairing. •Beyond the warranty period or does not belong to the free warranty products, the company's maintenance center is still dedicated to serve you. Contact detail: • If you need special customization or have requirements for delivery time, please contact sales manager: daiyi@chinachenyue.com WhatsApp: +86 173 5260 0137 M: +86 173 5260 0137 Service: +86 400 019 2928

Product Features NMRV series worm gear reducer has the following main features: 1. High quality aluminum table gold please make: light weight, no rust: 2. Large output torque; 3. Smooth transmission, low noise: suitable for long-term continuous work in harsh environments; 4. High heat dissipation efficiency: 5. Beautiful and durable, small size 6. It can be installed in all directions. Main materials 1. Shell: aluminum alloy (frame: 025-090), cast iron (frame: 110-150); 2. Worm: 20Cr, carburized and quenched, tooth surface hardness 56-62HRC, after fine grinding to maintain carburized layer thickness 0.3-0.5mm; 3. Worm gear: wear-resistant tin bronze. Surface coating Aluminum alloy shell: 1. Shot blasting treatment, and then by special anti-corrosion treatment, to maintain silver-white metal feeling, and resistance to gasoline, xylene and other organic solvents corrosion: 2. After phosphating treatment, spray RAL5010 blue or silver paint. Cast iron shell: first coated with red anti-rust paint, then spray RAL5010 blue paint. Key features • Factory outlet, provide video-outgoing inspection • Colors: Blue or gray or green or according to customer required • Die-cast aluminum alloy housing • Worm wheel adopts high quality Tin Bronze • Certification: CE/RoHS/IAF/CNAS/ISO9001/ISO45001/ISO14001 • Bipolar reducers: available • Flange: round or square • Delivery time: 45 days • Approximate gross weight: 1.2 Kg/pc Key benefits • Maintenance-free, fully sealed(no need fill oil for whole life) • Good heat dissipation • Low temperature rise • Low noise, smooth operation • Long service life and more durability • Energy saving and high efficiency • Can be installed in any position and in all directions • Built-in fully synthetic lubricant Tip: • The whole worm gearbox is warranted for one year. • The starting date of the warranty period is subject to the date of the product invoice, please present the invoice when repairing. • Beyond the warranty period or does not belong to the free warranty products, the company's maintenance center is still dedicated to serve you. • If you need special customization or have requirements for delivery time, please contact sales manager: cosmona2023@gmail.com WhatsApp: +86 15957611571 M: +86 15957611571 Service: +86 400 019 2928
